Electronics & Telecommunication Engineering

Facilities







EMBEDDED SYSTEMS DESIGN LAB

Major Equipments

  • Cortex M3 Development Boards
  • ARM 9 Development Board (Linux , Wince Based)

Embdlab


COMMUNICATION ENGG. LAB-I

Major Equipments

  • Microwave Test Bench
  • Antenna Training Lab,  Amitec Make PLL Synthesized 40 MHz-4.3 GHz, 2 SMA Antennas
  • Spectrum Analyser Aplab Make GW-Instek 9KHz- 3GHz
  • Network Analyser, Anritsu Make Model: Ms2035b  2-Port, 1-Path Vector Network Analyzer (Vna), Vna Master (500 KHz To 6 GHz)


Communication lab

VLSI DESIGN  LAB

Major Equipments

  • Virtex 5 FPGA Development board
  • Zynq 7000 All Programmable SOC Development Board
  • Multisim (Simulation Tool) V12.0
  • Xilinx ISE 13.2 (25 users)
  • Microwind package V3.5
  • MATLAB 2012a+22 Toolboxes



VLSI  lab




DIGITAL LOGIC DESIGN  LAB

Major Equipments

  • Digital IC tester

Digital Electronics Lab




BASIC ELECTRONICS ENGG.  LAB

Major Equipments

  • Digital IC tester

Basic Electronics Lab




PROJECT LAB

Major Equipments

  • PCB Design Lab (Optical Power Meter, UVExposure, Etching Machine, Lab Chemicals)

Project Lab





DIGITAL SIGNAL PROCESSING   LAB

Major Equipments

  • DSP Starter Kit(DSK) TMS 320C6713 With CCS
  • Analog Discovery Kit

DSP Lab




ELECTRONICS DEVICES & CIRCUITS  LAB

Major Equipments

  • Digital Storage Oscilloscope

EDC Lab
