Electronics & Telecommunication Engineering

Infrastructural Details





LABORATORY-WISE EQUIPMENT DETAILS



Sr.
No.

Name of the
Laboratory

Major  Equipments/ Softwares

1

Electronics Devices
Circuits Lab I

CRO, Signal Generator, Dual DC
power supply,Single power supply, DMM, Linear IC tester Trainer Kit AC milivoltmeter
Software-Multisim 11,EDC Trainer Kits

2

Electronics Devices
Circuits Lab II

3

Communication
Engineering Lab I

CRO, Signal Generator, Dual DC
power supply,Single power supply, DMM,DSO ,MSOArbitrary w/f generator,RF signal Generator,Wobboloscope,Spectrum analyzer,Logic Analyzer,LISN ,Panasonic Plasma TV,Bnchmark FOC trainer,AVE trainer kit,VN trainer Kit DC trainer Kit, CT trainer Kit,OMC trainer Kit,TSS Trainer Kit
TVE Kits,DC Trainer Kits, Mobile & Broadband Comuunication Trainer Kits

4

Communication
EngineeringLab II

5

Electronic Design  Lab

CRO, Signal Generator, Dual DC
power supply,Single power supply, DMM, Stabilizer,OTDR
Spectrum Analyzer,Dell Laptop

6

Projects Lab

PC (HP Compaq),Dot matrix Printer,DM 6437 digital video development platform,DSO,PCB manufacturing set-up,Stabilizer,DSO, 70 MHz

7

Signal Processing
Lab

PC(Pentium IV),LAN T Trainer Model-NEU150390,UPS,Stabilizer,Scanner,DSP kits,GD camera, LCD Projector,Dot matrix printers,Software-MATLAB 6.5, Simulink, Multisim 7.0,  Mathwork Prduct MATLAB -7.0

8

Power Electronics Lab

CRO, Signal Generator, Dual DC
power supply,Single power supply, DMM,4-Channel DSO, Output power meter,Autotransformer,Power Electronics trainer kit,

9

Microwave Antenna Lab

Antenna trainer kits,Microwave Test Bench,

10

Instrumentation Lab

3702 Aplab 20 Mhz
Dual Trace Oscilloscope, Aplab 2 MHz Multi Waveform Signal Genrator,Function Generator,Regulated dual DC power supply,Digital Multimeter

11

Programming Lab

PC (HP Compaq),Lazer Printer
Software-Mathwork Prduct MATLAB -10.0

12

Embedded System
Design Lab I

PC(IBM) ,Dot MatrixPrinter,Sony projector,WINICE-universal in-circuit emulator,Universal Programmer model-superPro ,PCI-1711-BE multifunction card, PIC trainer board, 89C51 trainer module with peripherals,ARM 7 & 9 board,MMA,ESD,AMP trainer kits
Softwares-SC51,Triton,M3 Cortex LPC1768 ARM CORTEX Development Board with TFT Display,ARM 9 Developement Board oasis

13 Embedded System
Design  Lab II

14

Software Lab I

Lazer printer,Computers - Dell optilex 390DT ,Servo Stabiliser 10KVA & 15KVA,D-Link 24 port Network switch,Printers

15

Software  LabII

16

Digital  Electronics Lab

Digital trainer Kit, Servo Stabiliser 10KVA

17

VLSI Design
Lab I

PC (IBM), VLSI & VHDL Module,Sony LCD projector,LAPTOP (IBM),HP-ML 15043,Intel xeon cord core,Dotmatrix printers, Lazerjet Printer,Universal Multivendor Protoboard
Software-MICROWIND,Xilinx-6.2,Modelsim,DSP Edition User 25,VLSI Design software Xilinx make-1SE series US-ISE-FND version 6.2 ,Adobe Acrobat, Professional 6.0 AE,FPGA-A-Spartam 3 Trainer Kits

18

PG-Lab 1

Acer Version Desktop
2GB DDR3, Quad core processor,
320GB HDD, OS-Win 7 home basic
Acer 15.6 wide TFT
ARM 9 Kit,Xtreme DSP Development Platform,Software-Mathwork Prduct MATLAB -10.0 Triton IDE,Intel Atom Processors

19

PG-Lab2





LABORATORIES


  • All the laboratories are well equipped  and having high-speed internet connectivity  with major equipments used for compliance testing for industrial equipments .



  1. 1. ELECTRONICS DEVICES CIRCUITS LAB I



  • Practicals like analog circuits are conducted in this lab.
  • Instruments like CRO’s Signal Generators, DC Power supplies, and Socket boards required for practical’s are available there.
  1. 2. ELECTRONICS DEVICES CIRCUITS LAB II
  • Practicals like analog circuits are conducted in this lab.
  • Instruments like CRO’s Signal Generators, DC Power supplies, and Socket boards required for practical’s are available there.



  1. 3. COMMUNICATION ENGINEERING LAB I
  • Practical in the subjects like Analog Communication, Digital Communication are held.
  • Major equipments like Spectrum analyzer, Pattern generators, MSOs, DSOs.
  • Analog & Digital trainer kits TV trainer kits, Optical Fiber trainer kits, Microwave trainer kits.



  1. 4. COMMUNICATION ENGINEERING LAB II
  2. 5. ELECTRONIC DESIGN LAB
  • Practical in the subjects like Analog Communication, Digital Communication are held.
  • Major equipments like Spectrum analyzer, Pattern generators, MSOs, DSOs.
  • Analog & Digital trainer kits TV trainer kits, Optical Fiber trainer kits, Microwave trainer kits.

  • Control System kits like PID, PLC etc
  • Practical in the subjects like Mini project and Electronic Design are held.
  • PCB ETCHING.
  • DRILLING MACHINE.
  1. 6. PROJECTS LAB
  • Circuit Simulation Software.
  • PCB manufacturing setup.
  • DIP COATING.
  • UV EXPOSER.



  1. 7. SIGNAL PROCESSING LAB
  • Lab with PCs, printers, scanner.
  • DSP processor kits, LAN trainer Kit With Latest software like MATLAB and interfacing                      hardware.



  1. 8. POWER ELECTRONICS LAB
  • Lab with 4-channel DSO, power Scope etc.
  • Trainer kits of Power Electronics .


9.   MICROWAVE ANTENNA  DESIGN LAB

  • Fixed length  Fixed Frequency and Variable length Variable frequency Antenna Trainer kits.
  • Microwave Test Bench with Klystron and Gunn Diode.



10. INSTRUMENTATION LAB

  • Lab with CROs, Signal Generators, DC Power supplies.
  • OTDR (optical Time Domain Reflectometer).



11. EMBEDDED SYSTEM DESIGN LAB I



  • Software like SC51, Triton, Cortex.





12. EMBEDDED SYSTEM DESIGN LAB II

  • Universal programmer, Trainer kits of ARM 7/ARM 9 processor.





13. PROGRAMMING LAB

  • Circuit Simulation & , microcontroller & its peripheral kits.



14. SOFTWARE LAB I

  • Lab with PCs, printers.
  • OOPs And DSA Practicals are conducted.

15. SOFTWARE LAB II

  • Lab with PCs, printers.
  • OOPs And DSA Practicals are conducted.

16. DIGITAL  ELECTRONICS LAB

  • Digital trainer kits, ICs.for the practical under Digital Electronics.

17. VLSI DESIGN LAB

  • Lab with PCs, printers.
  • Software like Xilinx etc.
  • VLSI trainer kits like Spartan I, Spartan II, Spartan III

18. PG-Lab I

  • Lab with PCs, printers.

19. PG-Lab II

  • Lab with PCs, printers.

1. ELECTRONICS DEVICES CIRCUITS LAB I

EDClab1




2. ELECTRONICS DEVICES CIRCUITS LAB II

EDClab2


3. COMMUNICATION ENGINEERING LAB I

communication lab1



4. COMMUNICATION ENGINEERING LAB II

communicationn lab2

5. ELECTRONIC DESIGN LAB

electronic design lab


6. PROJECTS LAB

project lab


7. SIGNAL PROCESSING LAB

signal processing


8. POWER ELECTRONICS LAB

power elctronics



9.   MICROWAVE ANTENNA  DESIGN LAB

microwave antenna




10. INSTRUMENTATION LAB

instrumentation




11. EMBEDDED SYSTEM DESIGN LAB I

embedded system design lab 1




12. EMBEDDED SYSTEM DESIGN LAB II

embedded system design lab 2






13. PROGRAMMING LAB

programming lab


14. SOFTWARE LAB I

software lab1




15. SOFTWARE LAB II

software lab2






16. DIGITAL  ELECTRONICS LABdigital electronics






17. VLSI DESIGN LAB

VLSI design lab






18. PG-Lab I

PG1






19. PG-Lab II



pg2








All the classrooms are well-equipped with teaching aids like OHP, LCD projectors, etc making teaching - learning interesting





Class Room Scenario







HARDWARE & SOFTWARES :





Hardware above  Rs. 50,000 per Equipment :


•Arbitrary Wave Form Generator

•RF Signal Generator

•Wobboloscope,

•Spectrum Analyzer

•Logic Analyzer

•Optical Time Domain Reflectometer

•Benchmark FOC trainer

•LAN Trainer





SOFTWARES :

MICROWIND

•Xilinx-6.2 &Modelsim 5.7

•Xilinx 12.1 & Modelsim DSP Edition User 25

•VLSI Design software

•Xilinx make-1SE series US-ISE-FND version 6.2

• Mathwork Product MATLAB -10.0
Triton IDE

•Multisim 11 - User 10
